Explore our top-tier OEM architectural systems certified for windborne debris, anti-forced entry, and maximum thermal efficiency.
Comprehensive Technical Analysis of 6063-T6 Extrusions, Thermal Insulation Breakages, and Anti-Intrusion Hardware Systems.
Utilizing high-tensile 6063-T6 and 6005A-T6 structural aluminum profiles, our security frames achieve a yield strength exceeding 241 MPa. Wall thickness spans from 2.0mm to 3.5mm depending on load-bearing requirements, ensuring structural stability under high wind loads and physical impact force.
Engineered with PA66-GF25 (25% Glass Fiber Reinforced Polyamide) thermal break strips, our security entry profiles isolate interior and exterior thermal bridges. This architecture lowers global U-factors to under 0.24 BTU/h·ft²·°F while enhancing sound damping up to STC 45dB.
Integrated with European standard multi-point locking mechanisms (up to 7-point locking systems with anti-prying hooks), hardened steel deadbolts, and anti-drill cylinder guards designed to counter manual and mechanical break-in attempts compliant with EN 1627 RC3/RC4 grades.
Unlike standard architectural profiles, Grandex security profiles undergo a specialized dual-stage heat treatment process (T6 aging) that increases shear resistance by 38%. Combined with precision CNC profile milling, dimensional tolerance is held strictly within ±0.15mm across a maximum single length of 6.5 meters.
Cross-regional standards compliance verified through independent accredited test laboratories.
| Certification / Target Market | Wind Load / Structural Resistance | Water Tightness & Air Infiltration | Impact & Forced Entry Rating | Primary Commercial Use |
|---|---|---|---|---|
| Florida NOA / FPA North America High-Velocity Zone |
TAS 202 (Design Pressure up to ±100 PSF) | ASTM E331 Water Test (15 PSF Pass) | TAS 201 / 203 Large Missile Impact Level D | Coastal High-Rise, Luxury Villas, Commercial Facilities |
| NFRC Certified US & Canada Energy Codes |
NFRC 100/200 Thermal Rating Matrix | ASTM E283 Air Leakage <0.1 cfm/ft² | SHGC Range: 0.18 - 0.35 | U-Factor: 0.20 - 0.26 | Green Building Projects, Net-Zero Residential |
| AS2047 / AS1170 Australia & New Zealand |
Ultimate Limit State (ULS) up to 4500Pa | Serviceability Limit State (SLS) 450Pa Water | AS2208 Safety Glazing Standard Compliant | Residential High-Rises, Multi-family Apartments |
| EN 1627 / CE Mark European Union & UK |
EN 12210 Wind Resistance Class C5 | EN 12208 Water Tightness Class 9A | RC2 / RC3 / RC4 Resistance Class Security | Embassy Facilities, High-Security Residential, Banks |
Inside Grandex Door Solutions: 35,000 m² Automated Production Ecosystem Engineered for Zero-Defect OEM Delivery.
Our intelligent 5-axis CNC machining centers execute multi-dimensional drilling, slotting, and milling operations with micro-level accuracy (±0.05mm). This guarantees frictionless hardware installation and seamless miter joints across custom door frames.
Quality control operates under strict ISO 9001 protocols. Every profile batch undergoes spectral composition analysis, paint adhesion cross-hatch tests, and dynamic cycle testing (over 200,000 opening/closing cycles) prior to assembly.
Backed by more than 1,200 verified raw material and hardware partners, Grandex maintains guaranteed aluminum billet reserves, mitigating price volatility and securing stable 25-30 day manufacturing lead times for large-scale procurement.
Visualizing our raw material processing, robotic cutting, intelligent sorting, and certified laboratory testing workflow.
Pioneering smart access integration, structural decarbonization, and extreme thermal isolation technology.
Next-gen security systems integrate embedded micro-motor locks, concealed biometric scanners, dynamic RFID entry, and encrypted smart-home network integration (Matter / Zigbee protocols) while retaining physical security ratings.
Pioneering ultra-thin Vacuum Insulated Glass units with thermal performance matching solid walls (U-factors down to 0.08 BTU/h·ft²·°F), drastically cutting total door weight while maximizing sound insulation and bulletproof performance.
Advancing sustainability with 75%+ recycled primary aluminum extrusions powered by clean hydro-electric smelting. Achieving EPD (Environmental Product Declaration) certification for LEED-certified commercial green building tenders.
Tailored OEM architectural solutions designed for global commercial developers and specialized contractors.
For coastal resorts and waterfront high-rises in storm-prone regions like Florida and the Caribbean, our impact-rated doors feature laminated structural PVB/SGP interlayers and heavy-gauge reinforced aluminum frames capable of withstanding cyclic pressure forces up to ±100 PSF and direct missile impact tests.
Engineered for high-traffic public venues and hospitality projects. Includes UL-certified panic breakout hardware, fire-rated glass integration, electric push-bar release systems, and ADA-compliant low-profile threshold saddles designed for rapid egress safety compliance.
Combining contemporary slim-frame aesthetic designs with heavy-duty multi-point security locks. Provides developers with customizable surface finishes (powder coating, fluorocarbon PVDF, anodizing, wood grain sublimation) that withstand harsh coastal atmosphere corrosion for over 25 years.
Custom prefabricated door modules engineered for off-site modular housing construction. Features precision-engineered mounting flanges, pre-drilled anchors, and factory-installed perimeter weather-seals that accelerate on-site installation by up to 40%.
High-performance exit doors, lift-sliding systems, and thermal break French swing doors.
Clear, authoritative answers regarding engineering capabilities, OEM customizations, international logistics, and testing compliance.
Grandex provides full-spectrum OEM and ODM customization. Our 85-engineer R&D team supports tailored aluminum extrusion profiles, custom frame depths, specific thermal break polyamide widths, custom RAL powder coating colors, anodized metal textures, specialized decorative glass (smart switchable electrochromic, triple-pane Low-E, laminated security glass), and custom hardware integration from top European and American brands (such as Hoppe, Siegenia, GU, and Yale).
Our security doors incorporate multi-point locking systems with anti-drill manganese steel plates, heavy-duty continuous or 3D adjustable security hinges rated for up to 300kg sash loads, and structural 6063-T6 aluminum frames with internal steel reinforcing cores. Glazing units use laminated safety glass with SGP (SentryGlas®) interlayers, securing EN 1627 RC3/RC4 ratings and ASTM anti-burglary standard compliance.
Our high-impact product line is independently tested and certified under Florida Building Code Notice of Acceptance (NOA) and Florida Product Approval (FPA). They comply with TAS 201 (Large Missile Impact Test), TAS 202 (Uniform Static Air Pressure), and TAS 203 (Cyclic Wind Pressure Loading), making them approved for High-Velocity Hurricane Zones (HVHZ) including Miami-Dade and Broward counties.
All aluminum extrusions undergo automated pre-treatment chromating followed by AkzoNobel or PPG PVDF (Fluorocarbon) liquid coating or QUALICOAT-certified thermosetting powder coatings. Surface finishes are tested via ASTM B117 Neutral Salt Spray testing for over 3,000 to 5,000 hours without blistering, chalking, or color fading, making them optimal for beachfront developments.
Standard custom production lead time is 25 to 35 business days following final approval of engineering shop drawings. For standard commercial project profiles, our flexible MOQ starts at 50 square meters. For custom profile extrusion dies, tooling fabrication takes 10 to 14 days with sample sign-off prior to mass production.
Grandex exports globally with annual revenues exceeding $28 Million USD. Products are packaged using multi-layer protection: protective film, foam corner protectors, vacuum shrink wrap, and fully enclosed IPPC-stamped fumigated plywood crates. We provide comprehensive DDP/CIF shipping logistics support, CAD/BIM shop drawings, and remote/on-site installation guidance for foreign commercial project developers.
